Name: KMPW520 Multi-Parameter Water Quality Analyzer with 7 Inch Touch Screen Display 6-Channel Relay Control and 2-Channel 4-20mA Output
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KMPW520
Price: 5,000.00 USD
Availability: InStock

집 > 상품 > 수질 감지 센서 >

KMPW520 Multi-Parameter Water Quality Analyzer with 7 Inch Touch Screen Display 6-Channel Relay Control and 2-Channel 4-20mA Output

7 inch touch screen display Water Quality Analyzer

6-channel relay control Water Quality Analyzer

2-channel 4-20mA output Water Quality Sensor

원래 장소:

치안

브랜드 이름:

KACISE

인증:

모델 번호:

KMPW520

저희와 연락

인용 을 요청 하십시오

KMPW520 Multi-Parameter Water Quality Analyzer with 7 Inch Touch Screen Display 6-Channel Relay Control and 2-Channel 4-20mA Output

제품 세부 정보

작업 조건:

0~60℃, 습도 ≤ 90%

전원공급장치:

AC 220V

크기:

223mm × 200mm × 120mm

무게:

10.51kg

설치방법:

벽걸이 설치

보호 수준:

IP65

강조하다:

7 inch touch screen display Water Quality Analyzer

6-channel relay control Water Quality Analyzer

2-channel 4-20mA output Water Quality Sensor

지불 및 배송 조건

최소 주문 수량

1개

포장 세부 사항

각 장치에는 개별 상자가 있으며 모든 상자에는 표준 패키지에 포장되거나 고객 요청이 가능합니다.

배달 시간

5-8 근무일

지불 조건

L/C,D/A,D/P,T/T,웨스턴 유니온,MoneyGram

공급 능력

주당 1000 조각/조각 협상 가능

KWS-790 Digital pH Sensor with 0.00–14.00 pH Measuring Range ±0.02 pH Accuracy and 0–99.9 ℃ Temperature Compensation

가장 좋은 가격 을 구하라

KMPW520 Multi-Parameter Water Quality Analyzer with 7 Inch Touch Screen Display 6-Channel Relay Control and 2-Channel 4-20mA Output

가장 좋은 가격 을 구하라

TDLAS302 Laser Methane Sensor with 0.1 ppm Resolution and 0–1000 ppm Measurement Range for High Accuracy Gas Analysis

가장 좋은 가격 을 구하라

0.00-20.00mg/L 측정 범위, ±2%F.S. 정확도, 0.01mg/L 분해능을 갖춘 벽걸이형 온라인 광학식 용존 산소(DO) 측정기

가장 좋은 가격 을 구하라

저희와 연락

86--17719566736

지금 연락하세요

제품 설명

KMPW520 Multi-Parameter Water Quality Analyzer

Product Configuration

Electronic Cabinet x 1
Controller × 1
Sensors for the controller
User manual

Product Introduction

The KMPW520 Multi-Parameter Water Quality Analyzer is a next-generation monitoring system featuring digital sensors for flexible parameter combinations. Designed for industrial applications, it offers comprehensive control capabilities with multiple analog and relay channels, supporting Modbus-RTU protocol for remote data transmission.

Main Features

RTOS system for enhanced performance, stability, and real-time monitoring
7-inch touch screen with English menu and multi-parameter display
6 freely configurable data channels with selectable measurement units
6-channel relay control with high/low alarm settings
2-channel 4-20mA analog output with adjustable ranges
2-channel RS-485 digital interface supporting MODBUS-RTU protocol
Sensor calibration and configuration tools including factory reset
Data logging to TF card (up to 32GB) and USB export capability
Password protection and dual interface themes
Historical data visualization with curves and records

Technical Specifications

Measurement Parameters:

Temperature, PH, ORP, conductivity, TDS, salinity, dissolved oxygen, residual chlorine, dissolved ozone, turbidity, TSS, sludge concentration, hardness, ion concentration, Resistivity, COD, BOD, etc.

Parameter Combinations:

Maximum 6 parameters in free combination (examples: PH+ORP+conductivity+DO+residual chlorine+turbidity)

Specification	Details
Power Supply	AC 220V
Dimensions	223mm × 200mm × 120mm
Weight	1.51kg
Installation	Wall-mounted
Operating Conditions	0-60℃, humidity ≤90%
Protection Level	IP65
Input Interface	6-channel RS485 with 12V power supply (1A total capacity)
Analog Output	2-channel 4-20mA (750Ω load capacity per channel)
Relay Control	6 channels (3A load capacity per channel)
Digital Output	2-channel RS485 (Modbus-RTU protocol)
Display	7.0-inch LCD (800×480 resolution), capacitive touch
