원래 장소:
중국
브랜드 이름:
KACISE
인증:
CE
모델 번호:
KLF110
| Speed measurement range | 0.1 m/s -30m/s |
|---|---|
| Speed measurement accuracy | ±0.01ms (radar simulator calibration) |
| Blind area for ranging | 8cm |
| Maximum range for ranging | 60m |
| Ranging accuracy | ±1mm |
| Specification | Value |
|---|---|
| Speed measurement range | 0.1 m/s - 30 m/s |
| Speed measurement accuracy | ±0.01 m/s (radar simulator calibration) |
| Speed measurement pitch angle (auto compensation) | 0-80° |
| Speed measurement antenna beam angle | 12°×25° |
| Ranging blind area | 8 cm |
| Maximum ranging distance | 60 m |
| Ranging accuracy | ±1 mm |
| Ranging antenna beam angle | 6° |
| Power supply range | 9-28 VDC |
| Working current | 25 mA @12V |
| Communication interface | RS485 |
| Communication protocol | Modbus (9600/115200) |
| Operating temperature | -30°C to 70°C |
| Housing material | Aluminum alloy, PBT |
| Dimensions | 142 mm × 84 mm × 94 mm |
| Protection rating | IP68 |
| Installation method | Bracket |
