원래 장소:
중국
브랜드 이름:
KACISE
인증:
CE
모델 번호:
KSINS001C
| Attribute | Value |
|---|---|
| Power Voltage | 18~32VDC |
| Power | <40W |
| Position Accuracy | <0.05%D; <0.5nmile/h |
| Attitude Accuracy | <0.02° |
| Heading accuracy | <0.3mil |
| Power Supply Parameters | |
|---|---|
| Power Voltage | 18~32VDC |
| Power | <40W |
| Product Performance | |
| Position Accuracy | <0.05%D; <0.5nmile/h |
| Attitude Accuracy | <0.02° |
| Heading accuracy | <0.3mil |
| Circular Error Probable (CEP) | <0.1m |
| Velocity Accuracy | <0.6m/s |
| Alignment Time | <5min |
| Gyroscope Specifications | |
| Bias stability | ≤ 0.001°/h; ≤ 30μg |
| Bias repeatability | ≤ 0.001°/h |
| Scale factor temperature sensitivity | 5ppm; 50ppm; 50ppm |
| Random walk | ≤ 0.0005°/√h |
| Accelerometer Specifications | |
| Bias stability | ≤ 30μg |
| Bias repeatability | ≤ 30μg |
| Scale factor repeatability | 50ppm |
| Scale factor temperature sensitivity | 50ppm |
| Environmental Specifications | |
| Operating temperature | -40~+65°C |
| Random vibration | GJB150.16A-2009.C.3 |
| Shock | 30g,11ms |
| Interfaces | |
| Output | RS-422 × 2; RS-232 × 1; Ethernet interface; CAN bus interface; Odometer interface × 1; Altimeter interface; Speedometer interface |
| Physical Specifications | |
| Size | 300×250×220mm |
| Weight | <15kg |
